1.5T MRI-HMF | Helium‑Free Superconducting MRI System with AI Technology

Helium‑free 1.5T superconducting MRI system with zero‑liquid‑helium technology, 36 mT/m gradients, AI‑powered imaging, and silent scanning. Ideal for hospitals and diagnostic centers.

The Global Healthcare Medical SKY 1.5T MRI-HMF is a revolutionary helium‑free superconducting MRI system that eliminates the need for liquid helium cooling. Traditional MRI systems depend on liquid helium to cool superconducting magnets, but liquid helium is scarce, expensive, and environmentally impactful. The helium‑free design conserves resources, reduces maintenance costs, and mitigates operational risks.

This innovative system revolutionizes MRI technology through the SO‑COOL cryogenic conduction platform, incorporating cutting‑edge technologies such as ultra‑efficient cryogenic conduction, high‑vacuum confinement, and precise temperature control. Featuring an AI imaging operation platform, the SKY 1.5T MRI-HMF enhances image quality and speeds up imaging processes. Designed to meet the demands of modern healthcare facilities, this system delivers exceptional performance while significantly reducing operational costs and environmental impact.

This device is intended for professional use in clinical settings by trained healthcare professionals. Not a substitute for professional medical diagnosis.

Key Features

❄️ Zero‑Liquid‑Helium Technology (SO‑COOL)

The SKY 1.5T MRI-HMF is built on a revolutionary solid conduction cooling design that requires 0 liters of liquid helium. Key advantages include:

• No liquid helium needed – Eliminates costly helium refills and ongoing supply concerns

• No quench pipe required – Flexible site conditions with simplified installation

• Environmentally sustainable – Reduces reliance on scarce helium resources

• Lower operating costs – No ongoing helium maintenance expenses

• Reduced operational risks – Mitigates risks associated with helium supply and handling

🧲 High‑Performance 1.5T Superconducting Magnet

The SKY 1.5T MRI-HMF features a 1.5‑Tesla superconducting magnet with a 60 cm bore diameter and a compact 1.55 m magnet length. This design offers:

• Excellent magnetic field uniformity – Enables large FOV imaging and rapid acquisition

• Short‑bore configuration – Reduces patient claustrophobia and improves comfort during examinations

• Superior anatomical coverage – Ideal for whole‑body imaging without patient repositioning

📊 Advanced Gradient & RF Performance

The system delivers high‑performance imaging capabilities:

🤖 AI‑Powered Operation Workflow

The SKY 1.5T MRI-HMF integrates an AI‑based operation workflow that transforms the imaging experience:

• Whole body imaging driven by ART hardware – Optimized image acquisition

• Simplest positioning process – Simplified by the AiTO engine

• Higher quality image reconstruction – Powered by the Hyper.Recon algorithm

• AI imaging operation platform – Enhances image quality and speeds up imaging processes

🖼️ Superior Image Quality

The system delivers more accurate imaging through multiple advanced technologies:

• Multiple fat suppression solutions – Enhanced tissue differentiation

• Multiple artifact reduction technologies – Cleaner, clearer images

• Higher spatial resolution imaging – In less scan time

🔇 Patient‑Centric Productivity

The SKY 1.5T MRI-HMF prioritizes patient comfort and workflow efficiency:

• SoftScan (SoftSound 2.0) – Generates silent acoustic noise for a more comfortable patient experience

• Super.Sense – Accelerates daily scan throughput

• mCS technology – Realizes higher quality images in the same scanning time and accelerates daily throughput in whole‑body applications

📈 Comprehensive Clinical Applications

The SKY 1.5T MRI-HMF supports a wide range of advanced clinical applications:

Abdominal Imaging:

• T1_DCE with Gd‑DTPA – 3D MPR reconstruction precisely visualizes lesion spatial location

• mCS technology – 16‑second breath‑hold captures dual arterial phase, reducing missed diagnosis and enhancing accuracy

MRCP (Magnetic Resonance Cholangiopancreatography):

• Heavy T2WI – Based on high signal of bile and pancreatic juice

• 1.5mm original slice thickness – Based on FSE 3D_VFA sequence

• 3D MIP reconstruction – Clear visualization

• 18‑second breath‑hold – With mCS technology

MRA (Magnetic Resonance Angiography):

• Non‑CE MRA – Based on enhanced effect of blood inflow

• MIP reconstruction – Clearly displays blood vessel morphology and direction

• 33% less scanning time – Compared to standard MRA

🏥 Environment Requirements

The system is designed for flexible installation with minimum scanning room size of 30 m². No quench pipe is required, allowing for simplified site conditions.

Specifications

What's Included

• SKY 1.5T MRI-HMF Main System

• Superconducting Magnet (1.5T, 60cm bore, helium‑free)

• SO‑COOL Solid Conduction Cooling System

• Gradient Coil System (36 mT/m, 136 T/m/s)

• RF System (16 channels, 20 kW)

• AI Imaging Operation Platform

• Patient Table

• RF Coils (configuration varies)

• System Control Console

• Installation and Training Support

• User Manual

Applications

The SKY 1.5T MRI-HMF is suitable for:

• Hospitals & Medical Centers – Comprehensive diagnostic imaging across all departments

• Diagnostic Imaging Centers – High‑throughput, high‑quality imaging services

• Research Institutions – Advanced clinical research and functional imaging studies

• Neurology & Neurosurgery – Brain and spine imaging

• Abdominal Imaging – Liver, kidney, pancreas, and biliary imaging

• Vascular Imaging – Non‑contrast MRA and contrast‑enhanced angiography

• Oncology – Tumor detection, staging, and treatment monitoring

• Musculoskeletal – Joints, spine, and soft tissue evaluation

Why Choose the SKY 1.5T MRI-HMF?



FAQ

Q: What is the SKY 1.5T MRI-HMF?

A: The SKY 1.5T MRI-HMF is a helium‑free superconducting MRI system that eliminates the need for liquid helium cooling. It features SO‑COOL cryogenic conduction technology, AI‑powered imaging, and zero‑liquid‑helium operation.

Q: What is the field strength and bore size?

A: The system offers a 1.5 Tesla field strength with a 60 cm bore diameter.

Q: Does the system require liquid helium?

A: No. The SKY 1.5T MRI-HMF requires 0 liters of liquid helium thanks to its revolutionary SO‑COOL solid conduction cooling design.

Q: What is the gradient performance?

A: The system features 36 mT/m gradient amplitude and 136 T/m/s slew rate for fast, high‑quality imaging.

Q: What AI technologies are included?

A: The system features an AI imaging operation platform that enhances image quality and speeds up imaging processes. It includes AiTO engine for simplified positioning and Hyper.Recon algorithm for higher quality image reconstruction.

Q: Does the system support silent scanning?

A: Yes. The SKY 1.5T MRI-HMF features SoftScan (SoftSound 2.0) technology that generates silent acoustic noise for improved patient comfort.

Q: What is the minimum scanning room size?

A: The system requires a minimum scanning room size of 30 m². No quench pipe is required, simplifying installation.

Q: What clinical applications is the system suitable for?

A: The SKY 1.5T MRI-HMF is suitable for abdominal imaging (T1_DCE), MRCP, MRA, neurological, musculoskeletal, oncological, and vascular imaging.

Q: What is the delivery lead time?

A: The delivery lead time is approximately 7–30 days.

Q: What is the warranty period?

A: The system comes with a 1‑year warranty for the machine. Spare parts damaged due to quality issues will be replaced free of charge during the warranty period.
