Class B Dental Sterilizer 18L/23L Drying Dental Autoclave Steam Sterilizer #

Class B Dental Sterilizer 18L/23L Drying Dental Autoclave Steam Sterilizer #

Regular price $1,916.20
Regular price $0.00 Sale price $1,916.20
Sale Sold out
Shipping calculated at checkout.
Volume

Model:GHM060322

Features:

1. It fit EN13060 standard with opening tank on the top which is convenient to cleaning.
2. Standard Class B with three times vacuum and drying, the remaining temperature of sterilized instrument is less than 0.2%.
3. The vacuum data can reach -0.8bar, it fits various instrument, including package, unpacked, solid, hollow, multi-apertures and inset pipes. It makes sure the instrument can be sterilized completely.
4. Fuzzily computer controlled, digital bright show. The interface is modularized panel for easy operation.
5. It is installed with BOWIE&DICK which measures the penetration of water steam.
6. it has vacuum text which can make sure the ability of texting vacuuming.
7. Sterilization cycle self-comment.
8. Fast and independent steam generator.
9. Large capacity instrument tray made of SS. SU304.
10. Safety lock and triple temperature.overload protecting
11. Inset cleaning device
12. Special function of creating medicine cotton and sterilizing rubber items
13. Handsome aspect and good quality
14. 4-Button operation panel, so convenient.
15. Mini printer is able to be connected which can record the sterilizer information.
16. Warning message, Error is made easier to judge.


Main Parameter:

Volume 18L/23L
Sterilization Class CLASS B
Sterilization Temperature 121℃,134℃
Special Program HIV, HBV long-sterilization program
Dry System  Vacuum drying system
Testing System Bowie&Dick Test
Vacuum Test
Helix Test
Control Precision Temperature: 1℃
Pressure: 0.1bar
Safety System Relief valve,Hand lock door ,Pressure lock system,Pressure and temperature over load protection,Alarm system
Water Supply System Build-in water tank easy to clean
Cubage:3.5or 4L
Tray Rack 5-layer tray rack with 3 trays
Chamber Medical stainless steel 304
Max working pressure:2.3bar
Min working pressure: -0.9bar
Max temperature: 145℃
Operation Temperature 5~40℃
Noise <50db
Water consumption in one cycle 0.16L~0.18L



Program List:

Program Temperture Pressure Pre-Vacuum SteriizationTime  DryingTime
UNPACKED 134℃ 2.1bar 1 4mins 9mins
PACKED 134℃ 2.1bar 3 5mins 9mins
PRION 134℃ 2.1bar 3 18mins 9mins
POROUS 121℃ 1.1bar 3 20mins 18mins
