EDAN eSE-300 Electrocardiograph

The EDAN eSE-300 is a lightweight, full-touch 3-channel resting electrocardiograph designed for routine 12-lead ECG acquisition, analysis, display, and recording in hospitals, clinics, and healthcare facilities. At approximately 1 kg, it is built for handheld transport between examination rooms, consultation areas, and inpatient bedsides, with a built-in rechargeable lithium-ion battery and built-in thermal printer that support operation without immediate access to mains power or a separate printing device.

The eSE-300 acquires 12-lead ECG signals simultaneously through body surface electrodes, processes the signals using EDAN’s SEMIP algorithm (optional configuration), and outputs 3-lead reports on 80 mm thermal paper, with 4 pages in series to cover all 12 leads. The full-touch screen supports direct menu navigation and waveform review, and the unit includes 8 GB of internal storage for ECG records and patient data.

The eSE-300 is part of the SE-3 / SE-300 series, which received FDA 510(k) clearance under K091513 (July 24, 2009) and K171943 (September 25, 2017) , and carries China NMPA registration (粤械注准20252070962) . Its cleared intended use covers adult and pediatric patients (beginning at birth through 21 years of age) for ECG signal acquisition via body surface electrodes, to assist in heart disease analysis. Per the cleared labeling, ECG measurements and interpretive statements are offered to clinicians on an advisory basis only and do not replace clinical judgment.

The eSE-300 is designed for facilities that need a compact, touch-operated ECG device for routine resting ECG workflows—with the acquisition, printing, storage, and connectivity features required for everyday clinical use, without the footprint or cost of a larger 12-channel system.

Key Features & Benefits

Approximately 1 kg, Handheld Form Factor

At roughly 1 kg, the eSE-300 is designed for single-hand carrying between rooms and bedsides. The compact enclosure supports use in space-constrained consultation rooms, outpatient clinics, and bedside ECG workflows where a cart-mounted system would be impractical.

Full-Touch Screen for Direct Operation

The full-touch screen replaces conventional button-based navigation with direct on-screen interaction for menu selection, waveform review, and settings adjustment. This simplifies operation for staff who perform ECGs intermittently and reduces the learning curve for routine workflows.

Simultaneous 12-Lead Acquisition with 3-Channel Thermal Output

The eSE-300 acquires 12-lead ECG signals simultaneously, then outputs 3-channel reports on an 80 mm thermal printer, with 4 pages in series to output all 12 leads. The built-in thermal printer produces standard Z-fold or roll recording paper, supporting immediate hard-copy documentation at the point of care without a separate printer.

SEMIP Algorithm for Measurements and Interpretive Statements (Advisory)

The SEMIP algorithm (optional configuration) processes the acquired ECG signals to provide measurements and interpretive statements for clinician review. Per the cleared labeling, these statements are offered on an advisory basis only—they are intended to support, not replace, clinician assessment.

8 GB Internal Storage and Built-In Battery

The eSE-300 includes 8 GB of internal storage for ECG records and patient data, reducing reliance on external media for routine recordkeeping. The built-in rechargeable lithium-ion battery supports operation away from mains power, and the included power adapter supports recharging between uses.

Flexible Connectivity and Data Export Options

The eSE-300 supports optional DICOM, FDA-XML, and SCP export formats for integration with hospital information systems and ECG management workflows. SE-1515 Data Management Software (optional) is available for centralized ECG review, storage, and reporting. Optional 4G cellular connectivity and barcode scanner options (linear or 2D) support patient identification and data transmission in networked or mobile settings.

Flexible ECG Cable and Electrode Configuration

The eSE-300 is available with 12-lead ECG cables in banana connector, snap, or clip terminations, in IEC or AHA configurations. Standard accessories include adult precordial suction electrodes and adult limb clamp electrodes; pediatric electrodes and disposable ECG electrodes are available as options. This allows facilities to standardize on the cable and electrode format already used in their department.

Mounting and Workflow Accessories

An optional rolling stand (MT-206, with basket and counterweight) and mounting plate support cart-based use, while a cable arm (CA-100) keeps lead wires organized during exams. A dust cover is available for storage protection.
