EDAN M3 Vital Signs Monitor
EDAN M3 Vital Signs Monitor
The EDAN M3 is a compact, durable vital signs monitor designed for efficient spot checks and short-term monitoring in outpatient clinics, general wards, and sub-acute care settings. Featuring a 5.6-inch high-resolution color TFT-LCD screen, the M3 delivers essential physiological measurements—SpO₂, NIBP, pulse rate, and temperature—in a lightweight, portable design that fits easily into daily clinical workflows.
Proven to be a durable and efficient solution for outpatients and general wards, the M3 brings effective vital signs monitoring to most ambulatory and regular healthcare environments. With flexible configuration options, multiple blood pressure measurement modes, and a built-in rechargeable lithium-ion battery providing up to 14 hours of continuous operation, the M3 is a reliable, cost-effective solution for hospitals, clinics, and primary care settings.
The M3 is FDA 510(k) cleared (K131818) for non-invasive continuous monitoring of SpO₂, NIBP, and temperature, and is suitable for adult, pediatric, and neonatal patients.
Key Features & Benefits
Essential Vital Signs Monitoring
The M3 provides core physiological measurements required for routine patient assessment:
| Parameter | Description |
|---|---|
| SpO₂ | Oxygen saturation of arterial blood with pulse rate and plethysmogram (PLETH) |
| NIBP | Non-invasive blood pressure with systolic (SYS), diastolic (DIA), and mean arterial pressure (MAP) |
| PR | Pulse rate measurement |
| TEMP | Temperature measurement via optional Covidien Quick Temp, Infrared Ear Temp, or T2/TH/F3000 modules |
The monitor is suitable for adult, pediatric, and neonatal patients, with visual and audible alarms for physiological parameters that exceed operator-set limits.
Flexible Configuration Options
The M3 series offers multiple configuration choices to match specific clinical needs:
| Configuration | SpO₂ | NIBP | Temperature |
|---|---|---|---|
| SpO₂ only | ✓ | — | — |
| NIBP only | — | ✓ | — |
| SpO₂ + NIBP | ✓ | ✓ | — |
| NIBP + Quick Temp | — | ✓ | ✓ |
| SpO₂ + NIBP + Quick Temp | ✓ | ✓ | ✓ |
The M3A variant includes an infrared ear thermometer for rapid temperature measurement, while the M3 supports Covidien Quick Temp options.
Multiple Blood Pressure Measurement Modes
The M3 offers four NIBP modes to suit different clinical scenarios:
-
Auto mode – automatic interval measurement
-
Manual mode – on-demand measurement
-
Continuous mode – rapid sequential measurements
-
Average mode – calculated average for trending
User-Friendly Design & Display
-
5.6-inch high-resolution color TFT-LCD screen – clear numeric and waveform display
-
Lightweight and portable – easy to carry between patient rooms
-
Real-time measurement display with trend table – quick review of patient data
-
Simple interface – minimal training required for daily operation
Powerful Data Management & Connectivity
-
100-hour trend data for all parameters (SYS, MAP, DIA, PR, SpO₂, TEMP)
-
USB flash disk support for data export
-
HL7 support via XML files or MFM-CMS for EMR integration
-
Bi-directional communication with MFM-CMS central monitoring system
-
CMS Lite PC data management software compatibility
-
Wired LAN/WiFi support for network connectivity
-
Barcode scanner support for streamlined patient identification
-
Nurse call feature for immediate clinical alerts
Extended Battery Life
-
Built-in rechargeable lithium-ion battery
-
Up to 14 hours of continuous operation on a single charge
-
AC power supply for continuous operation when needed
Technical Specifications
| Specification | Detail |
|---|---|
| Display | 5.6-inch color TFT-LCD, high resolution |
| SpO₂ Range | 0–100%; accuracy ±2% (adult/pediatric, 70–100%), ±3% (neonate, 70–100%) |
| NIBP Range | Adult: SYS 25–290 mmHg; Pediatric: SYS 25–240 mmHg; Neonatal: SYS 25–140 mmHg |
| PR Range | 40–240 bpm |
| TEMP Range | 25°C–45°C (depending on module) |
| NIBP Modes | Auto, Manual, Continuous, Average |
| Alarm Types | Visual and audible alarms for physiological parameters and system faults |
| Trend Storage | 100-hour trend data for all parameters |
| Data Export | USB flash disk, HL7/XML, PDF |
| Connectivity | Wired LAN, optional WiFi, USB port, barcode scanner support |
| Central Station | Bi-directional communication with MFM-CMS; CMS Lite PC software |
| Battery | Built-in rechargeable lithium-ion, up to 14 hours continuous use |
| Power Supply | 100–240 V~, 50/60 Hz |
| Patient Types | Adult, pediatric, and neonatal |
| Regulatory | FDA 510(k) cleared (K131818); IEC 60601-1; IEC 60601-1-2; IEC 60601-2-49 compliant |
| Intended Use | Non-invasive continuous monitoring of SpO₂, NIBP, and TEMP in hospitals and hospital-type facilities; intra-hospital moves; under regular supervision of clinical personnel |
Why Choose the EDAN M3?
| Clinical Challenge | M3 Solution |
|---|---|
| Routine vital signs spot checks | Quick, reliable measurements with SpO₂, NIBP, PR, and optional TEMP |
| Flexible configuration needs | Multiple configuration options to match clinical requirements and budget |
| Extended clinical use | Up to 14-hour battery life on a single charge |
| Blood pressure measurement flexibility | Auto, Manual, Continuous, and Average modes for different scenarios |
| Data transfer to EMR/HIS | HL7 support, USB export, and MFM-CMS bi-directional communication |
| Patient identification efficiency | Barcode scanner support for streamlined workflow |
| Caregiver notification | Nurse call feature for immediate clinical alerts |
| Portability between patient rooms | Lightweight design with clear 5.6-inch color display |
