EDAN SE-100 Electrocardiograph

The EDAN SE-100 is a single-channel, portable resting electrocardiograph designed for routine 12-lead ECG acquisition, real-time waveform preview, and integrated thermal recording in clinics, hospitals, and primary care settings. It pairs a foldable LCD screen (192 × 64 pixels, 80 × 27 mm) for waveform preview with a built-in high-resolution thermal printer that produces single-channel recordings on 50 mm × 30 m thermal paper.

The SE-100 is built around complete digital filtering—EMG filtering at 35 Hz, AC/DFT filtering at 50/60 Hz, and automatic baseline adjustment—to keep the trace readable during acquisition. The device supports manual mode plus three pre-configured automatic modes, allowing facilities to standardize acquisition sequences across users with different levels of ECG experience. Lead-off detection and alarm notify the user when an electrode loses contact, supporting acquisition quality.

Power is supplied by a built-in rechargeable lithium-ion battery or AC/DC mains, with battery operation supporting up to 150 continuous ECG records depending on configuration and usage. The waterproof membrane keyboard supports routine wipe-down between patients, and the compact enclosure is designed for transport between examination rooms and bedside locations.

The SE-100 carries CE marking under MDD 93/42/EEC as a Class IIa device (Rule 10) , certified through TÜV SÜD Product Service GmbH (notified body 0123). The device is designed to IEC 60601-1, IEC 60601-1-2, and IEC 60601-2-25 safety and performance standards, and is classified as Class I with internal power supply, Type CF, defibrillation-proof; it is not suitable for use in the presence of flammable anesthetics. The SE-100 shares its single-channel platform with the SE-1 model, and the two share the core recording architecture and accessory ecosystem.

The SE-100 is built for facilities that need a straightforward, single-channel ECG device with preview display, integrated thermal printing, multiple automatic acquisition modes, and battery-backed portability—without the footprint or cost of a multi-channel system.

Key Features & Benefits

Foldable LCD Screen for Pre-Recording Waveform Preview

The 192 × 64-pixel LCD screen displays the ECG waveform in real time before recording begins, allowing the clinician to confirm signal quality, electrode contact, and baseline stability at the point of acquisition. The screen folds down when not in use, reducing the device footprint during transport and storage.

Built-In High-Resolution Thermal Printer

The integrated thermal printer produces single-channel ECG recordings on 50 mm × 30 m thermal paper, eliminating the need for a separate printing device at the bedside or in the consultation room. The printer is part of the main unit, so acquisition and hard-copy documentation happen in a single step.

Manual Mode Plus Three Pre-Configured Automatic Modes

The SE-100 supports manual operation and three automatic recording modes, allowing the user to choose between full manual control and pre-configured acquisition sequences. This flexibility supports both experienced ECG technicians who prefer manual lead control and staff who perform ECGs intermittently and benefit from standardized automatic workflows.

Complete Digital Filtering and Automatic Baseline Adjustment

The SE-100 applies EMG filtering at 35 Hz (−3 dB) , AC/DFT filtering at 50/60 Hz, and automatic baseline adjustment to counter drift during recording. These filters are designed to support trace readability without requiring manual re-adjustment between patients.

Lead-Off Detection and Alarm

The device includes lead-off detection and alarm, which alerts the user when a patient electrode is disconnected or making poor contact. This supports acquisition quality by drawing attention to cable or electrode issues before they affect the recording.

Rechargeable Li-Ion Battery with AC/DC Power

The built-in rechargeable lithium-ion battery supports operation away from mains power, with up to 150 continuous ECG records cited in product documentation. The device can also run on AC/DC power, with automatic switching between power sources. The battery is designed to support a full clinic session or extended bedside use without immediate access to mains power.

Compact Enclosure with Waterproof Membrane Keypad

The waterproof membrane keyboard supports routine wipe-down between patients. The compact, portable design is intended for transport between examination rooms, clinics, and bedside locations, with carrying bag and rolling stand options available for protected transport and cart-based deployment.

Safety Classification: Class I, Type CF, Defibrillation-Proof

The SE-100 is classified as Class I with internal power supply, Type CF (defibrillation-proof applied part) under IEC 60601-1. The patient connection is fully isolated, and the device is defibrillation-proof, supporting use in settings where defibrillation may occur. It is not explosion-proof and is not suitable for use in the presence of flammable anesthetics.
