EDAN X10 VET Veterinary Monitor

The EDAN X10 VET is the 10.1-inch mid-tier model in EDAN’s X VET series—a veterinary multi-parameter monitor positioned between the compact X8 VET and the full-size X12 VET. It carries the same ultra-slim, no-fan chassis as the rest of the series, but adds a larger display, 2-channel temperature, and optional invasive blood pressure (IBP) capability that the X8 VET does not offer.

Standard parameters on the X10 VET include 3/5-lead ECG, RESP, EDAN SpO₂, EDAN NIBP, PR, and dual-channel TEMP, running on EDAN’s iSEAP™ ECG, iMAT™ SpO₂, and iCUFS™ NIBP algorithms. The optional full-touch 10.1-inch screen provides direct on-screen interaction, while canine and feline alarm programs arrive pre-configured for species-appropriate threshold behavior.

For anesthetic and critical-care workflows, the X10 VET can be configured with EDAN G2 sidestream CO₂ (iCARB™ algorithm with pseudo-wave identification and a water trap design) and 2-channel IBP, alongside esophageal probe options that combine ECG and core temperature in a single lead. Data management covers 1,200 NIBP records, 240 hours of trend data, 200 alarm and arrhythmia events, and 48 hours of full-disclosure waveforms, with USB export and optional built-in 32 GB SD card storage.

The X10 VET is built for clinics that want a larger viewing area and hemodynamic capability without moving to the X12 VET footprint—the same algorithms, accessories ecosystem, and no-fan architecture, scaled to a mid-sized enclosure.

Key Features & Benefits

10.1-Inch Display in an Ultra-Slim, No-Fan Chassis

The 10.1-inch color TFT-LCD (800 × 480) sits in a cabinet that measures just 41 mm at its thinnest point and weighs < 2.8 kg without battery—compact enough for single-hand transport via the built-in handle, yet large enough for multi-waveform viewing at a distance. The fanless cooling design eliminates operating noise and prevents dust accumulation on internal fan blades and grilles, supporting use in surgical suites and recovery areas with strict dust-control expectations.

Dual-Channel Temperature (T1 / T2)

Unlike the single-channel X8 VET, the X10 VET supports 2-channel temperature (T1 and T2) as standard. This enables simultaneous monitoring of two temperature sites—for example, core and peripheral—without adding a second device. The optional esophageal probe combines ECG and core body temperature in one lead, simplifying cable management when rectal temperature measurement is not practical.

Optional Invasive Blood Pressure (IBP)

The X10 VET is the smallest model in the X VET series to offer optional 2-channel IBP. For procedures and critical patients where non-invasive cuff readings are insufficient, IBP adds direct pressure waveform monitoring alongside the standard NIBP parameter—a capability not available on the X8 VET.

Canine & Feline Alarm Programs, Plus User Configuration

The X10 VET ships with Canine, Feline, Other, and User-Configured alarm programs, activated automatically when the corresponding patient type is selected. This means the monitor arrives with species-appropriate default alarm behavior for the two most common small-animal patients, while retaining full customization for individual cases or other species.

Optional Full-Touch Screen with Customizable Shortcuts

The optional full-touch 10.1-inch display adds direct on-screen parameter selection and menu navigation. The customizable shortcut menu along the bottom of the display places frequently used functions—alarm review, trend review, NIBP start/stop, and printing—within one tap. A waterproof silicone button shield supports routine wipe-down between patients.

EDAN G2 Sidestream CO₂ with iCARB™

When configured with the EDAN G2 CO₂ module, the X10 VET adds sidestream capnography with the iCARB™ algorithm for intelligent CO₂ pseudo-wave identification, a water trap design to protect the monitor from humidity, and a breath tone that provides an audible cue to real-time respiratory changes. This makes the X10 VET suitable for both routine vital-signs monitoring and anesthetic procedures where EtCO₂ trends are part of the workflow.

ECG with iSEAP™: 33 Arrhythmia Types and Auto Lead Detection

The iSEAP™ ECG algorithm supports auto-detection of 33 arrhythmia types, automatic lead placement detection to reduce false alarms, and customized filtering for cleaner waveforms. The monitor is defibrillation-proof and ESU-protected, with defibrillator synchronization available through the optional VGA/analog output interface.

SpO₂ with iMAT™: Motion and Low-Perfusion Performance

EDAN’s iMAT™ SpO₂ algorithm is designed for motion resistance and low-perfusion performance, with a Perfusion Index (PI) reference reading that reflects perfusion changes at the sensor site. Veterinary-specific SpO₂ sensors are available as part of the X VET accessories ecosystem.

Data Review, Export, and Night Mode

The X10 VET stores 1,200 NIBP records, 240 hours of trend data, 200 alarm events, 200 arrhythmia events, and 48 hours of full-disclosure waveforms. Data can be exported via USB or retained on an optional built-in 32 GB SD card. Night mode dims the display for low-light recovery areas, and thermal printing (optional) supports hard-copy documentation.
