*This type of table is used for the surgeries of chest, abdomen,ophthalmology, obstetrics, and urology, etc. *The board can shift longitudinally and it can be X-rayed with C-ARM even to take photos. *All posture adjustment,including the table height adjustment, forward and backward and left and right titling are all controlled by keys operation and fueled by the electro-push rod device.The folding of the back section and the leg board is motivated by the force of the spring and gravity. *The manipulator used with 24V DC is easy to operate, safe and reliable. *The leg board is dismantable. It is manual rotation and could be outreached with the force from the spring and gravity, convenient for urology surgery. *Length/Width:2100mm/550mm *Height:700-1000mm *Trendelenburg/ Revers Trendelenburg:≥25°/≥25° *Lateral Tilt:≥15°/≥15° *Head Section Up/Down:≥45°/≥90° *Leg Section Up/ Down/ Outside:≥15°≥90°/≥180° *Back Section Up/ Down:≥80°/≥17° *Sliding Distance:≥350mm *Kidney Bridge Lift:120mm
