GHM H650 Fully Auto Glycated Hemoglobin Analyzer #

Extreme Speed for High Throughput

• Standard Mode: 60 seconds/test

• Variant Mode: 96 seconds/test
  Ideal for busy clinics and labs needing rapid HbA1c and variant analysis.

Ultra‑Low Sample Volume

• Whole blood: only 3 μL

• Hemolysis mode: 80 μL

• B‑thalassemia mode: 8 μL
  Minimizes patient discomfort, especially for pediatric and geriatric testing.

Comprehensive Hemoglobin Variant Detection
Tests HbA1c, HbF, HbA1a, HbA1b, LA1c, HbA0, HbC, HbD, HbE, HbS, and HbA2 – all in one analyzer.

Superior Repeatability
CV ≤ 1% – delivering exceptional precision for confident clinical decisions.

Fully Automated Cap‑Piercing
Accepts whole blood or hemolysis samples without manual pre‑treatment, reducing errors and hands‑on time.

Long‑Life Consumables

• Analytical column: 2,000 tests

• Sieve plate (filter): 600 tests

Massive Data Storage
Stores up to 100,000 sample results – perfect for long‑term patient tracking and busy laboratory environments.

Comprehensive Reporting
Reports include: HbA1a, HbA1b, HbF, LA1c, A1c, HbA0, A2, and variant proteins C, D, S, E.

Calibrator & Control Sets Available
HbA1c Calibrator Set and HbA1c Control Set ensure ongoing accuracy and regulatory compliance.

Robust & Compact Design

• Dimensions: 575mm (L) × 350mm (W) × 545mm (H)

• Weight: 35 kg

• Power supply: 85–264 VAC – universal voltage for global installation.

✅ Why Choose the H650?

The H650 offers the fastest test speed (60s) among GHM’s HPLC analyzers, combined with the lowest whole blood sample volume (3 μL) and the broadest variant panel – making it the ideal choice for high‑efficiency diabetes and thalassemia screening.
