Global Healthcare Medical

GHM IMS-972 Plus Semi-auto B Electrolyte Analyzer #

GHM IMS-972 Plus Semi-auto B Electrolyte Analyzer #

$1,689.00
$1,689.00
Sale Sold out
Shipping calculated at checkout.

Product Features – GHM IMS-972 Plus Semi-auto B Electrolyte Analyzer

4.3″ Touch Screen – Simple & Intuitive
Enjoy a modern, easy‑to‑use interface with real‑time sample ID display. The simple menu makes operation effortless – no extensive training required.

Fast 80 Tests Per Hour
Results in ≤45 seconds per sample. Handles routine and emergency workloads with ease – ideal for busy hospitals and labs.

Extended Panel: K⁺, Na⁺, Cl⁻, TCO₂ + Anion Gap
Beyond basic electrolytes, measure total carbon dioxide (TCO₂) and automatically calculate Anion Gap (AG) – essential for acid‑base and metabolic assessment.

Sleep Mode Reduces Reagent Costs
Automatically lowers reagent consumption when idle. Individual reagent design eliminates waste – significantly cuts operating expenses.

39 Sample Positions
Includes 5 emergency ports and 4 functional positions – always ready for STAT requests without interrupting routine runs.

Built‑in Thermal Printer & RS232 Port
Print results instantly or connect to LIS/HIS systems via RS232 for seamless data management.

Smart Maintenance for Reliable Accuracy

  • Automatically detects and filters tiny bubbles – prevents clogs, ensures precise results

  • Wave flushing + direct flushing pipe method – no blockages, no cross‑contamination

  • Automatic calibration with two‑point correction (slope and intercept)

  • Real‑time system working status diagnosis

Power Failure Protection
Safely stores up to 10,000 test results – no data loss during unexpected shutdowns.

RTC Clock Management
Timestamp every result for accurate records and quality control tracking.

Print QC Graphs & Statistical Parameters
Easily monitor assay performance with printable QC charts and statistics – meets lab compliance requirements.

Low Consumption, High Value
Minimizes reagent and consumable costs while delivering lab‑grade accuracy.

Compact, Space‑Saving Design

  • Dimensions: 380×296×433 mm (L×W×H) – shorter than previous models

  • Net weight: 8 kg

  • Power: AC220V ±22V, 50Hz ±1Hz, ≤120W

  • Operating temperature: 10–30°C

Precision You Can Trust



Parameter Measuring Range Resolution Precision (CV%)
K⁺ 0.50–20.00 mmol/L 0.01 mmol/L ≤1.5%
Na⁺ 15.0–200.0 mmol/L 0.1 mmol/L ≤1.5%
Cl⁻ 15.0–200.0 mmol/L 0.1 mmol/L ≤1.5%
TCO₂ 2.0–70.0 mmol/L 0.1 mmol/L ≤3.5%
AG Calculated – –

Perfect for hospitals, emergency rooms, dialysis centers, and labs that need routine electrolytes plus TCO₂ and anion gap for acid‑base monitoring – the IMS‑972 Plus Type B combines touchscreen simplicity with powerful metabolic insight.
