Polaris50 E U-arm Digital Diagnostic Radiography System #

Versatile U-Arm DR for Efficient Human Radiography
The Polaris50 E is a digital diagnostic radiography system featuring a flexible U-arm design — engineered for hospitals and clinics requiring efficient, high-quality imaging for a wide range of human radiographic examinations.

High-Frequency Generator for Superior Performance
Powered by the HFG E high-voltage generator, the system delivers stable, consistent X-ray output with optimized dose management.

Toshiba X-Ray Tube – Proven Reliability

• X-ray tube model: Toshiba E7876X

• Brand: Trusted Toshiba imaging technology

Engineered for consistent, high-quality X-ray output in demanding clinical environments.

Large-Format Digital Detector for Full-Frame Imaging

• Detector model: GHM50-4343F-C

• Detector size: High-resolution digital flat panel detector

Captures high-quality radiographic images with excellent detail for confident diagnosis.

Precision Collimation for Optimal Beam Control

• Collimator model: INNOVA C20

Provides precise X-ray beam control to minimize patient dose and improve image quality.

Flexible U-Arm Radiography Frame

• Frame model: GHM50-J3U radiography frame

• Design: U-arm configuration for flexible positioning

The U-arm design allows for a wide range of exam types with easy patient access and positioning.

Motorized Transport Bed for Patient Comfort

• Bed model: GHM50-MT transport bed

Motorized bed enables effortless patient positioning for various radiographic procedures.

Professional Imaging Workstation

• Console: GHM20-ConsoleU

• Software: DROC digital radiography system

• Computer: Dell desktop computer

Complete digital imaging workstation with intuitive controls and efficient workflow management.

Fixed Grid for Scatter Reduction

• Grid specification: 10:1 ratio, 40 L/cm, 18" × 18"

Ensures cleaner images by minimizing scattered radiation.

Standard AEC for Dose Optimization

• AEC: Automatic Exposure Control included as standard

Automatically adjusts exposure parameters for consistent image quality and optimized patient dose.

Complete System Package

• Power distribution box: Included

• AC power: 3-phase AC380V, 50/60Hz, EU plug

• Certificate: CE certified

Ready-to-install complete system with all necessary components.

For human use only — This system is designed and certified for human diagnostic radiography.
