Anesthesia Ventilator Machines: CPAP, BiPAP, Emergency & HFNC Ventilator Guide
Understanding Ventilator Types
Ventilator technology spans a spectrum from simple home sleep apnea devices to advanced hospital-grade systems. Understanding the categories helps match the right device to clinical needs.
Four Categories of Ventilator Support
| Category | Pressure Range | Primary Use | Care Setting | Price Range |
|---|---|---|---|---|
| CPAP / Auto-CPAP | 4–20 hPa | Obstructive sleep apnea | Home | $461–$650 |
| BiPAP / Bi-Level | 4–30 hPa | COPD, complex sleep apnea, OHS | Home / Hospital | $601–$900+ |
| Emergency / Transport | Variable | Patient transfer, disaster response | EMS / Field | $2,460–$3,600 |
| HFNC Systems | Up to 80 L/min | Acute respiratory failure | Hospital / Clinic | $3,600 |
CPAP vs BiPAP: Key Differences
- CPAP delivers one continuous pressure to keep airways open — sufficient for straightforward obstructive sleep apnea.
- BiPAP (Bi-Level) delivers two pressures: a higher inspiratory pressure (IPAP) and a lower expiratory pressure (EPAP), reducing the work of breathing for patients with COPD, neuromuscular disease, or obesity hypoventilation syndrome.
- BiPAP ST adds a timed backup rate for patients who cannot maintain spontaneous breathing — critical for central sleep apnea and severe COPD.
- TVAPS (Target Volume Assured Pressure Support) automatically adjusts pressure to guarantee a target tidal volume — the most advanced non-invasive mode.
Home Care CPAP & BiPAP Devices
Non-invasive home ventilators deliver positive airway pressure through a mask, treating sleep-disordered breathing and chronic respiratory conditions without intubation. These devices feature quiet operation (below 28 dB), compact form factors, and touchscreen interfaces.
1. CPAP APAP BIPAP Ventilator Non-Invasive Home Ventilator (GHM01S06)
This multi-mode home ventilator spans the full CPAP-to-BiPAP range in four sub-models. The GHM01S06A delivers basic CPAP, while the GHM01S06D adds S, T, and S/T modes for complex respiratory conditions. A 5-inch touch LCD and 4 GB data storage support long-term therapy management.
From $461.80| Model | GHM01S06A / B / C / D |
|---|---|
| Therapy Modes | A: CPAP | B: CPAP/APAP | C: CPAP/S/S-Auto | D: CPAP/APAP/S/S-Auto/T/S-T |
| Pressure Range | A-B: 4–20 cmH₂O | C: 4–25 cmH₂O | D: 4–30 cmH₂O |
| Sound Level | <28 dB(A) |
| Display | 5-inch touch LCD |
| Data Storage | 4 GB (1 year) |
| Power Supply | 100–240 VAC, 50/60 Hz |
| Dimensions | 271.5 × 143 × 139.5 mm |
| Alerts | Mask leak, high pressure, high temperature, humidifier leakage |
2. Auto-Adjusting CPAP Device with Humidifier
This auto-adjusting CPAP device automatically titrates pressure within the 4–20 hPa range based on real-time airway resistance detection. The integrated humidifier prevents airway dryness, while the 3-year warranty and CE/ISO 13485 certification ensure clinical-grade reliability.
$650.00| Therapy Mode | Auto-CPAP (APAP) |
|---|---|
| Pressure Range | 4–20 hPa |
| Humidifier | Integrated |
| Certification | CE, ISO 13485 |
| Warranty | 3 years |
3. Portable BIPAP NIV Ventilator Machine (GHM01S01)
This portable non-invasive ventilation (NIV) device offers five sub-models (A–E) to match clinical needs. The compact design supports both home use and patient transport, with multi-mode therapy ranging from basic CPAP to advanced BiPAP with S/T modes.
From $601.50| Model | GHM01S01A / B / C / D / E |
|---|---|
| Price Range | $601.50–$684.00 |
| Type | Non-Invasive Ventilator (NIV) + HFNC |
| Tags | NIV ventilator & HFNC |
4. Smart CPAP Machine for Women (GHM SS110)
Specifically calibrated for women's respiratory patterns, the SS110 delivers auto-adjusting CPAP therapy with pressure range 4–20 hPa. The compact design and quiet operation suit bedroom environments, while the smart algorithm adjusts to female-specific airway dynamics.
Request a Quote| Model | GHM SS110 |
|---|---|
| Therapy Modes | CPAP, Auto-CPAP |
| Pressure Range | 4–20 hPa |
| Target Patient | Women with sleep apnea |
Advanced Bi-Level Ventilators
For patients requiring more than simple CPAP, bi-level ventilators deliver dual-pressure support with advanced modes like S/T (spontaneous/timed) and TVAPS. These devices bridge the gap between home therapy and hospital-grade respiratory support.
5. Bi-Level Non-Invasive Ventilator — BPAP ST with Humidifier (GHM BPAP ST25)
The BPAP ST25 delivers bi-level therapy with a timed backup rate, supporting patients who need pressure support but cannot reliably maintain spontaneous breathing. The integrated humidifier and ST mode make it suitable for COPD and central sleep apnea management.
$850.00| Model | GHM BPAP ST25 |
|---|---|
| Therapy Mode | Bi-Level PAP with ST (Spontaneous/Timed) |
| Max Pressure | 25 hPa |
| Humidifier | Included |
| Certification | CE, ISO 13485 |
| Warranty | 3 years |
6. High-Performance Bi-Level Ventilator — ST Mode, 30 hPa (GHM BPAP ST30)
The BPAP ST30 extends the ST25's capabilities with a 30 hPa maximum pressure, supporting patients with severe respiratory conditions requiring higher pressure support. The ST mode ensures a timed backup respiratory rate for patients with compromised respiratory drive.
$900.00| Model | GHM BPAP ST30 |
|---|---|
| Therapy Mode | Bi-Level PAP with ST (Spontaneous/Timed) |
| Max Pressure | 30 hPa |
| Indications | Severe sleep apnea, COPD, respiratory insufficiency |
| Certification | CE, ISO 13485 |
| Warranty | 3 years |
7. Bi-Level Pulmonary Ventilator (GHM SS160)
The SS160 offers five therapy modes — CPAP, APAP, S, T, and S/T — with a 25 hPa maximum pressure. This positions it between basic home CPAP and advanced hospital BiPAP, covering a wide clinical range from sleep apnea to pulmonary disease management.
Request a Quote| Model | GHM SS160 |
|---|---|
| Therapy Modes | CPAP, APAP, S, T, S/T (5 modes) |
| Max Pressure | 25 hPa |
| Indications | COPD, sleep apnea, pulmonary disease |
Emergency & Transport Ventilators
Emergency ventilators are engineered for reliability in unpredictable conditions — power outages, ambulance transport, disaster response, and field medicine. They prioritize durability, simplicity, and power-independent operation.
8. Shangrila935 Classic Emergency Ventilator
The Shangrila935 operates entirely on pneumatic drive — no electricity, batteries, or generators required. This makes it ideal for remote areas, power outages, and emergency transport where power access is unavailable. Built-in high/low-pressure alarms and adjustable oxygen concentration provide essential safety controls.
$2,460.00| Drive Type | Pneumatic (power-free) |
|---|---|
| Key Feature | No electrical dependence — no batteries needed |
| Safety | High/low-pressure alarms |
| Oxygen | Adjustable O₂ concentration |
| Use Case | EMS, field rescue, disaster response, hospital ER |
| Maintenance | Low — no electrical components to replace |
9. Shangrila510 Emergency Transport Ventilator
The Shangrila510 holds the distinction of being China's first CE-marked emergency transport ventilator and the sole designated emergency ventilator for the Olympic Games. Used in over 130 countries, it combines pneumatic drive with electronic control, supports triple power options (A/C, D/C, built-in battery), and features one-step parameter setting with real-time waveform display.
$3,600.00| Drive Type | Pneumatically driven, electronically controlled |
|---|---|
| Power Options | A/C (wall), D/C (vehicle), built-in rechargeable battery |
| Certification | CE-marked (China's first emergency transport ventilator) |
| Global Reach | 130+ countries |
| Operation | One-step parameter setting, waveform display |
| Safety | Backup apnea ventilation (auto-trigger on detected apnea) |
| Installation | Ambulance-mounted or bedside |
High-Flow Nasal Cannula (HFNC) Systems
HFNC systems deliver heated, humidified oxygen at high flow rates through a nasal cannula, providing an intermediate level of respiratory support between non-invasive ventilation and invasive intubation. They reduce work of breathing while maintaining patient comfort.
10. NeoHif i5 Respiratory Humidifier Ventilator (HFNC)
The NeoHif i5 is a comprehensive HFNC system with dual flow modes — Low (2–25 L/min) for mild support and High (10–80 L/min) for acute respiratory needs. Four preset dew-point temperatures (29°C/31°C/34°C/37°C), adjustable FiO₂ (21–100%), PM2.5 filtration, and voice alarm system make it a versatile respiratory support platform for hospitals, clinics, and home care.
$3,600.00| Flow Modes | Low: 2–25 L/min | High: 10–80 L/min |
|---|---|
| FiO₂ Range | 21%–100% (adjustable) |
| Dew-Point Temps | 29°C / 31°C / 34°C / 37°C |
| Humidification | ≥12 mg/L (29–36°C) | ≥33 mg/L (37°C) |
| Monitoring | Temperature, flow, FiO₂, respiratory rate; optional SpO₂/PR |
| Filtration | PM2.5 integrated filter |
| Alarm | Voice alarm system |
| Noise Level | ≤45 dB(A) at 80 L/min |
| Weight | 3 kg (310mm × 175mm × 185mm) |
| Safety Rating | Class II, BF; IP21 waterproof |
| Warranty | 1 year |
Additional Products
Beyond the 10 products detailed above, the collection includes these additional ventilator and respiratory support devices:
- Advanced Auto-Adjusting Bi-Level Ventilator (GHM SS195) — 8 therapy modes including TVAPS, 30 hPa max pressure. For COPD, complex sleep apnea, neuromuscular disease, OHS, restrictive lung disease. Request a Quote
- Advanced TVAPS Bi-Level Ventilator — Auto-adjusting ST ventilator with target tidal volume assurance. Request a Quote
- Sleep Apnea Treatment CPAP APAP BIPAP Oxygen Machine — Non-invasive home ventilator. From $520.10
- APAP CPAP Household Sleeping Therapy Device — Non-invasive home ventilator. From $533.30
- Emergency Transport Ventilator Transfer Medical Ventilator — For patient transfer. $2,706.00
- Respiratory Therapy Ventilator Hospital Ventilation Machine — Hospital-grade ventilation. $3,351.00 (was $4,199)
Buying Guide: Choosing the Right Ventilator
By Therapy Mode & Clinical Need
| Condition | Recommended Mode | Recommended Devices | Price Range |
|---|---|---|---|
| Obstructive sleep apnea (mild-moderate) | CPAP / Auto-CPAP | GHM01S06A/B, AutoCPAP, SS110 | $461–$650 |
| COPD, complex sleep apnea | BiPAP S/T | GHM01S06C/D, BPAP ST25, SS160 | $660–$850 |
| Severe respiratory insufficiency | BiPAP ST 30 hPa | BPAP ST30, SS195 (TVAPS) | $900+ |
| Emergency patient transport | Pneumatic / Transport | Shangrila935, Shangrila510 | $2,460–$3,600 |
| Acute respiratory failure (non-invasive) | HFNC | NeoHif i5 | $3,600 |
By Care Setting
| Setting | Suitable Devices | Key Requirements |
|---|---|---|
| Home / Bedroom | GHM01S06, AutoCPAP, SS110, Portable BIPAP | Quiet (<28 dB), compact, touch LCD, data storage |
| Hospital ward | BPAP ST25/ST30, SS160, NeoHif i5 | Higher pressure, multi-mode, monitoring capabilities |
| EMS / Ambulance | Shangrila935, Shangrila510 | Power-independent, durable, one-step operation |
| ICU / Critical care | NeoHif i5, Hospital Ventilation Machine | High flow, FiO₂ control, comprehensive monitoring |
By Budget Tier
| Tier | Price Range | Devices | Clinical Capability |
|---|---|---|---|
| Entry (Home CPAP) | $461–$650 | GHM01S06A, AutoCPAP | Single pressure, sleep apnea only |
| Mid (Home BiPAP) | $601–$900 | Portable BIPAP, BPAP ST25, BPAP ST30 | Dual pressure, S/T modes, COPD support |
| Emergency | $2,460–$3,600 | Shangrila935, Shangrila510 | Pneumatic drive, transport, disaster response |
| Advanced (HFNC) | $3,351–$3,600 | NeoHif i5, Hospital Ventilation Machine | High-flow oxygen, full monitoring, ICU-level support |
Frequently Asked Questions
What is the difference between CPAP and BiPAP ventilators?
CPAP delivers a single fixed pressure to keep airways open, primarily for sleep apnea. BiPAP delivers two pressure levels — a higher inspiratory pressure and a lower expiratory pressure — making it suitable for COPD, complex sleep apnea, and more severe respiratory conditions.
What pressure ranges do these ventilators support?
Home CPAP devices typically support 4–20 hPa. BiPAP ST models range from 4–25 hPa (GHM BPAP ST25) to 4–30 hPa (GHM BPAP ST30). Advanced bi-level ventilators like the GHM SS195 support up to 30 hPa with 8 therapy modes including TVAPS.
Are these ventilators CE and ISO 13485 certified?
Yes. Global Healthcare Medical ventilators carry CE marking and ISO 13485 certification. The Shangrila510 was China's first CE-marked emergency transport ventilator and was designated as the sole emergency ventilator for the Olympic Games. Most devices include a 3-year warranty.
Can these ventilators be used at home?
Yes. The CPAP APAP BIPAP Home Ventilator (from $461.80), Auto-Adjusting CPAP Device ($650), and Portable BIPAP NIV Ventilator (from $601.50) are designed for home use. They feature compact designs, quiet operation below 28 dB, and 5-inch touch LCD displays.
What is an emergency transport ventilator?
Emergency transport ventilators are designed for use during patient transfer in ambulances or emergency situations. The Shangrila935 ($2,460) operates entirely on pneumatic drive with no electrical dependence. The Shangrila510 ($3,600) supports A/C, D/C, and built-in battery power, and is used in over 130 countries.
What is an HFNC system and when is it used?
A High-Flow Nasal Cannula system delivers humidified, heated oxygen at high flow rates through a nasal cannula. The NeoHif i5 ($3,600) offers dual flow modes (2–25 L/min low and 10–80 L/min high), adjustable FiO₂ (21–100%), and four dew-point temperatures. It is used for acute respiratory failure, post-extubation support, and reducing reliance on invasive ventilation.
How do I choose between a home CPAP and a BiPAP device?
Choose CPAP for simple obstructive sleep apnea. Choose BiPAP if you have COPD, complex sleep apnea, obesity hypoventilation syndrome, or need two distinct pressure levels. The GHM01S06 series offers 4 sub-models (A–D) spanning CPAP to full BiPAP with S/T modes, starting at $461.80.
What warranty do Global Healthcare Medical ventilators include?
Most CPAP and BiPAP devices include a 3-year warranty with CE and ISO 13485 certification. The NeoHif i5 HFNC system includes a 1-year warranty. Emergency ventilators like the Shangrila series are designed for long-term use with minimal maintenance requirements.
Find the Right Ventilator for Your Clinical Needs
From a $461 home CPAP to a $3,600 HFNC system — Global Healthcare Medical covers the full spectrum of respiratory support.
Browse the Full Ventilator Collection →
Prices and availability subject to change. CE and ISO 13485 certified. Visit product pages for current specifications and quote requests.
